• Country
• Germany

• Manufacturer / Brand
• Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen

• Year
• 1961 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 218970

• Number of Tubes
• 11

• Valves / Tubes
• ECC85 ECH81 EF89 EBF89 EM84 EAA91 ECC82 ECC83 ECC83 ELL80 ELL80

• Main principle
• Superheterodyne (common); ZF/IF 460/10700 kHz; Export model

• Tuned circuits
• 10 AM circuit(s)     13 FM circuit(s)

• Wave bands
• Broadcast, 2 Short Wave plus FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 110; 125; 150; 220; 240 Volt

• Loudspeaker
• 6 Loudspeakers

• Power out
• 17 W (unknown quality)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Sterling Tannhäuser USA Stereo High Fidelity Z338 - Nordmende, Norddeutsche Mende-

• Shape
• Tablemodel with Push Buttons.

• Dimensions (WHD)
• 690 x 385 x 290 mm / 27.2 x 15.2 x 11.4 inch

• Notes
• Sterling Tannhäuser Stereo High Fidelity ist ein Exportmodell für die USA.
  UKW/FM: 88...108 MHz, 2x KW/SW, MW/BC.
  Siehe auch das inländische Modell Tannhäuser Stereo 2/633 und Tannhäuser Stereo 1/633. .
  Ähnlich zu Sterling Tannhäuser High Fidelity E338 mit den Bereichen U-K-M-L.

• Net weight (2.2 lb = 1 kg)
• 16.8 kg / 37 lb 0.1 oz (37.004 lb)

• Author
• Model page created by Bernhard Nagel. See "Data change" for further contributors.
