• Country
• Germany

• Manufacturer / Brand
• Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen

• Year
• 1972 ??

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 252587

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 1

• Valves / Tubes

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Superheterodyne (common); ZF/IF 38900 kHz

• Wave bands
• VHF incl. FM and/or UHF (see notes for details)

• Details
• Remote Control (with wire or wireless)

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Power out
• 2 W (undistorted)

• from Radiomuseum.org
• Model: TP 8738 8.515 Ch= FVI/110 777.514B - Nordmende, Norddeutsche Mende-

• Dimensions (WHD)
• 580 x 389 x 367 mm / 22.8 x 15.3 x 14.4 inch

• Notes

• Farbfernseher mit 46cm 110° Inline Bildröhre.
  16 Senderspeicher,
  US-Fernsteuerung telecontrol 160.

• Net weight (2.2 lb = 1 kg)
• 22 kg / 48 lb 7.3 oz (48.458 lb)

• Literature/Schematics (1)
• -- Original-techn. papers.

• Author
• Model page created by a member from D. See "Data change" for further contributors.
