• Country
• Germany

• Manufacturer / Brand
• Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen

• Year
• 1964/1965

• Category
• Television- and Radio Receiver, perh. also + Rec. etc. (TV Radio)

• Radiomuseum.org ID
• 110033

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 1

• Valves / Tubes
• A25-10W

• Number of Transistors
• 35

• Semiconductors
• AF139 AF109 AF106 AF125 AF121 AF126 AF118 OC139 SFT353 AC117 AD132 OC430 OC44 AC127 AU101 AY101 AD131 OA90 1N54A AA118 V40C2 AA112 SZ9 SZ12 SZ5 SZ17 E45C50 E150C10 TV10 B30C2500

• Main principle
• Superhet with RF-stage; ZF/IF 38900/5500 kHz; 3 AF stage(s)

• Tuned circuits
• 9 FM circuit(s)

• Wave bands
• Wave Bands given in the notes.

• Power type and voltage
• Line / Storage batteries (perhaps also batteries) / 220 / 12 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 13 cm = 5.1 inch

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Transvisa 15 UHF/UKW Ch= 965.215.10 [Ausf. A] - Nordmende, Norddeutsche Mende-

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 265 x 230 x 290 mm / 10.4 x 9.1 x 11.4 inch

• Notes

• VHF/UHF/UKW. Mehrpreis für aufladbaren Batteriesatz = 225,- DM
  Jeder Halbleitertyp ist einmal gelistet.

  Siehe auch Nordmende Transvisa 15 Ausf. B mit leicht abweichender Transistorbestückung.

• Net weight (2.2 lb = 1 kg)
• 9.4 kg / 20 lb 11.3 oz (20.705 lb)

• Price in first year of sale
• 1,476.00 DM

• Source of data
• Handbuch VDRG 1964/1965

• Mentioned in
• Handbuch RFP 1964/65 S.86 (Thiele)

• Literature/Schematics (1)
• -- Original-techn. papers.

• Author
• Model page created by Bernd P. Kieck. See "Data change" for further contributors.
