- Country
- Belgium
- Manufacturer / Brand
- Novak (also Pontiac); Bruxelles
- Year
- 1965 ??
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 204232
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 16
- Valves / Tubes
- PCC189 PCF86 PCL86 PCL85 EF183 ECH84 PCC85 EBF89 ECC82 PCF82 PCL84 PCF80 PL500 PY88 DY87 A59-11W
- Number of Transistors
- 6
- Main principle
- Superheterodyne (common)
- Wave bands
- Wave Bands given in the notes.
- Power type and voltage
- Alternating Current supply (AC) / 110; 130; 220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- from Radiomuseum.org
- Model: 141/10 - Novak also Pontiac; Bruxelles
- Notes
- VHF only, UHF in option.
- Source of data
- -- Original-techn. papers.
- Literature/Schematics (1)
- Service manual
- Author
- Model page created by Dirk Taekels. See "Data change" for further contributors.
