- Country
- Belgium
- Manufacturer / Brand
- Novak (also Pontiac); Bruxelles
- Year
- 1961 ?
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 187999
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 21
- Valves / Tubes
- PCC88 PCF80 EF183 EF184 EF184 PCF82 PCF82 PCL84 EF183 EF184 EAA91 PCL86 EBF89 ECH83 PCF80 ECC82 PL36 PY88 DY87 PCL85 AW59-90
- Number of Transistors
- Main principle
- Superheterodyne (common)
- Wave bands
- Wave Bands given in the notes.
- Power type and voltage
- Alternating Current supply (AC) / 110; 127; 220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Wooden case
- from Radiomuseum.org
- Model: 2101 - Novak also Pontiac; Bruxelles
- Shape
- Tablemodel with Push Buttons.
- Notes
- Unit uses 10 additional germanium diodes.
VHF only, UHF option?
Switches between 625 and 819 lines automatically.
- Source of data
- -- Original-techn. papers.
- Author
- Model page created by Dirk Bladt. See "Data change" for further contributors.
