Tape Recorder 351-02
Novak (also Pontiac); Bruxelles
- Country
- Belgium
- Manufacturer / Brand
- Novak (also Pontiac); Bruxelles
- Year
- 1967 ??
- Category
- Sound/Video Recorder and/or Player
- Radiomuseum.org ID
- 275137
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 3
- Number of Transistors
- Semiconductors
- OA81 Selengleichrichter
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Details
- Tape Recorder
- Power type and voltage
- Alternating Current supply (AC) / 110; 125; 140; 160; 220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Power out
- 2.5 W (unknown quality)
- from Radiomuseum.org
- Model: Tape Recorder 351-02 - Novak also Pontiac; Bruxelles
- Dimensions (WHD)
- 370 x 350 x 180 mm / 14.6 x 13.8 x 7.1 inch
- Notes
-
Monaural taperecoder with 4 tracks, 2 heads, 3 speeds. Supplied with microphone. Frequency response (-6dB) at speeds:
- 4,75 cm/sec: 50 - 4000 Hz.
- 9,5 cm/sec: 50 - 8000 Hz.
- 19 cm/sec: 50 - 15000 Hz.
Bias frequency: 55 kHz.
- Mentioned in
- -- Original-techn. papers. (Novak Service)
- Author
- Model page created by Radiomuseum Olen Museum. See "Data change" for further contributors.
