H189U -01 -02

NSF Nederlandsche Seintoestellen Fabriek, Hilversum

Data
Forum
Pictures
Collections

  • Year
  • 1946
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 133944

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 4
  • Main principle
  • Superheterodyne (common); ZF/IF 452 kHz; 2 AF stage(s)
  • Tuned circuits
  • 6 AM circuit(s)
  • Wave bands
  • Broadcast, Long Wave and Short Wave.
  • Power type and voltage
  • AC/DC-set / 110; 125; 200; 220 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 21.5 inch = 54.6 cm
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: H189U -01 -02 - NSF Nederlandsche
  • Shape
  • Tablemodel, low profile (big size).
  • Dimensions (WHD)
  • 525 x 335 x 240 mm / 20.7 x 13.2 x 9.4 inch
  • Notes
  • IF = 452 kHz in model U-01 and U-02. IF = 468 kHz in model U-00 and U-32.

    3 Band reception:
    • LW: 708 - 2000 m.
    • BC: 175 - 585 m.
    • SW: 13,7 - 51 m.
    Tuning scale light bulbs type: 2 x 8095D (19V, 90mA).
    Loudspeaker Philips type 9636-05 with built-in soundwave dispersing cone. Connectors for second loudspeaker and for pick-up.

    Attention: Chassis connected to the mains !
  • Net weight (2.2 lb = 1 kg)
  • 7.5 kg / 16 lb 8.3 oz (16.52 lb)
  • Literature/Schematics (1)
  • -- Original-techn. papers. (Generic model 189U by Philips dated 1946)
