• Country
• Germany

• Manufacturer / Brand
• NSM Aktiengesellschaft; Bingen

• Year
• 1974 ?

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 247857

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 16

• Semiconductors
• BC149 BC147 40361 40362 2N3055 BC177

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• Jukebox-Coin operated Phonograph

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• 2 Loudspeakers

• Material
• Wooden case

• from Radiomuseum.org
• Model: Jukebox Consul 120 [35M mono] - NSM Aktiengesellschaft; Bingen

• Shape
• Console with any shape - in general

• Dimensions (WHD)
• 850 x 1070 x 550 mm / 33.5 x 42.1 x 21.7 inch

• Notes

• Tonabnehmer: amplifier 35M, Sbb: DB102, Sicherungen: control and credit unit 41475 up to 0.6A, 1.6A, 2A, Schlüssel Key: 16767, Steuer-& Speichereinheit: Nr. 41475

  Lampen: cabinet: 1x TL30W/36"/T8; record indicator: 26x GE #19;
  select light: festoon lamp (Soffitte) S7 - 24V/3W
  credit unit: S8,5 - 24V/15W (or 18 Watt?)

  Weitere Serviceunterlagen sind beim Consul 120  mit Stereoverstärker

• Net weight (2.2 lb = 1 kg)
• 112 kg / 246 lb 11.1 oz (246.696 lb)

• Price in first year of sale
• 3,980.00 DM

• Author
• Model page created by Mario Darmann. See "Data change" for further contributors.
