• Year
  • 1967/1968
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 155871

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • 6
  • Main principle
  • Superheterodyne (common); ZF/IF 455 kHz
  • Wave bands
  • Broadcast only (MW).
  • Power type and voltage
  • Dry Batteries / 9 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5 cm = 2 inch
  • Power out
  • 0.2 W (unknown quality)
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Tivoli - Oceanic, deutsche Marke
  • Shape
  • Very small Portable or Pocket-Set (Handheld) < 8 inch.
  • Dimensions (WHD)
  • 65 x 105 x 33 mm / 2.6 x 4.1 x 1.3 inch
  • Notes
  • Ferritstab, Teleskopantenne. Anschluss für Ohrhörer. Lautsprecher 60 Ohm.

    Siehe auch Oceanic Split mit gleichem Chassis, aber abweichendem Gehäuse.

  • Net weight (2.2 lb = 1 kg)
  • 0.173 kg / 0 lb 6.1 oz (0.381 lb)
  • Mentioned in
  • -- Original-techn. papers.
  • Author
  • Model page created by Guido Höh. See "Data change" for further contributors.
