Pantophone 550 mit MW + LW
Odeon (Marke), International Talking Machine / Carl Lindström; Berlin
- Country
- Germany
- Manufacturer / Brand
- Odeon (Marke), International Talking Machine / Carl Lindström; Berlin
- Year
- 1929 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 199623
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 2
- Main principle
- TRF with regeneration
- Wave bands
- Broadcast (MW) and Long Wave.
- Power type and voltage
- Alternating Current supply (AC) / 110;125;150;220 Volt
- Loudspeaker
- Magnetic loudspeaker (reed) generic. / Ø 30 cm = 11.8 inch
- Material
- Wooden case
- from Radiomuseum.org
- Model: Pantophone 550 [mit MW + LW] - Odeon Marke, International
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 410 x 380 x 180 mm / 16.1 x 15 x 7.1 inch
- Net weight (2.2 lb = 1 kg)
- 7 kg / 15 lb 6.7 oz (15.419 lb)
- Author
- Model page created by Helge Witthandt. See "Data change" for further contributors.
