Hochspannungs-Netzgerät LS 529 R
Oltronix; Leek
- Country
- Netherlands
- Manufacturer / Brand
- Oltronix; Leek
- Year
- 1964
- Category
- Service- or Lab Equipment
- Radiomuseum.org ID
- 136077
Funkschau 23.1964
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 8
- Valves / Tubes
- EF86 EF86 EF86 12AU7 EF86 EF86 EL34 4-65A NE-2 NE-2 NE-2 NE-2 NE-2 NE-2 85A2 85A2 85A2 85A2
- Number of Transistors
- 2
- Wave bands
- - without
- Power type and voltage
- Alternating Current supply (AC) / 115; 220 Volt
- Loudspeaker
- - - No sound reproduction output.
- Material
- Metal case
- from Radiomuseum.org
- Model: Hochspannungs-Netzgerät LS 529 R - Oltronix; Leek
- Shape
- Chassis only or for «building in»
- Dimensions (WHD)
- 482 x 132 x 455 mm / 19 x 5.2 x 17.9 inch
- Notes
- Hochspannungs-Netzgerät LS 529 R.
Spannungsbereich 750...3400 V, Stromentnahme max. 30 mA; zur Versorgung von Photomultiplierröhren, Ionisationskammern und Zählröhren.
- Net weight (2.2 lb = 1 kg)
- 19 kg / 41 lb 13.6 oz (41.85 lb)
- Price in first year of sale
- 2,954.00 DM
- Source of data
- -- Original-techn. papers.
- Mentioned in
- Funkschau (23, 1964)
- Literature/Schematics (1)
- -- Schematic
- Author
- Model page created by Karlheinz Fischer. See "Data change" for further contributors.
