• Country
• United States of America (USA)

• Manufacturer / Brand
• Olympic Radio & Television, Inc.; New York (NY)

• Year
• 1958 ?

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 324561

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 14

• Valves / Tubes
• 2AF4A 5BK7A 5U8 6AU8 3DT6 12CU5 or 12C5 5B8 5B8 12BH7A 6CG7 12DQ6A 1B3GT 12AX4 17BJP4

• Main principle
• Superhet with RF-stage

• Wave bands
• Wave Bands given in the notes.

• Power type and voltage
• Alternating Current supply (AC) / 60 Hz, 117V = 110 -120 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: 17TU94MU Ch= GUU - Olympic Radio & Television,

• Shape
• Tablemodel, with any shape - general.

• Notes

• Olympic model 17TU94MU is a 17" b/w TV with US standard VHF tuner channels 2 thru 13. Equipped with chassis GUU, VHF tuner CL5583 and picture tube 17BJP4.



• Literature/Schematics (1)
• Photofact Folder, Howard W. SAMS (Set 395 Folder 2 dated 4-58)

• Author
• Model page created by Dirk Taekels. See "Data change" for further contributors.
