• Country
• Spain

• Manufacturer / Brand
• Ondina (Radio Eléctrica Solé S.A); Barcelona

• Year
• 1956 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 128760

• • alternative name: FEARE (Fabricación Española Aparatos Radio Electricidad)

• Number of Tubes
• 5

• Valves / Tubes
• ECH42 EAF42 EAF42 EL41 EZ41

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast and Short Wave (SW).

• Power type and voltage
• Alternating Current supply (AC) / 125 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 15 cm = 5.9 inch

• Material
• Wooden case

• from Radiomuseum.org
• Model: R 43 - Ondina Radio Eléctrica Solé S.

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 400 x 300 x 250 mm / 15.7 x 11.8 x 9.8 inch

• Net weight (2.2 lb = 1 kg)
• 11 kg / 24 lb 3.7 oz (24.229 lb)

• Source of data
• - - Data from my own collection

• Author
• Model page created by Diego Fernandez-Fernandez. See "Data change" for further contributors.
