• Country
• Japan

• Manufacturer / Brand
• Onkyo, Osaka Denki Onkyo K.K.; Osaka

• Year
• 2000 ??

• Category
• Loudspeaker, headphone or earphone

• Radiomuseum.org ID
• 281524

Click on the schematic thumbnail to request the schematic as a free document.

• Wave bands
• - without

• Power type and voltage
• No Power needed

• Loudspeaker
• 2 Loudspeakers

• Material
• Wooden case

• from Radiomuseum.org
• Model: Speaker System D-022A - Onkyo, Osaka Denki Onkyo K.K.;

• Shape
• Tablemodel, high profile (upright - NOT Cathedral nor decorative).

• Dimensions (WHD)
• 136 x 244 x 227 mm / 5.4 x 9.6 x 8.9 inch

• Notes

• Onkyo 2-Way Bass Reflex Speaker System Model D-022A.
  Frequency Response: 60Hz to 40kHz
  Power Handling: 70 Watts
  Crossover Frequency: 2700 Hz
  Impedance: 4 Ω
  Sensitivity: 84dB/W/m
  Drivers:
  Bass: 1 x 120mm OMF Cone Type (W1267B)
  Tweeter: 1 x 25mm Soft Dome Type (TW3181B)
  Enclosure: 4.8 litre, Bass Reflex Type
  Manuafactured in Malaysia

• Net weight (2.2 lb = 1 kg)
• 3 kg / 6 lb 9.7 oz (6.608 lb)

• Mentioned in
• - - Manufacturers Literature (Service Manual)

• Author
• Model page created by Franz Scharner. See "Data change" for further contributors.
