• Country
• Japan

• Manufacturer / Brand
• Onkyo, Osaka Denki Onkyo K.K.; Osaka

• Year
• 2000 ??

• Category
• Loudspeaker, headphone or earphone

• Radiomuseum.org ID
• 281535

Click on the schematic thumbnail to request the schematic as a free document.

• Wave bands
• - without

• Power type and voltage
• No Power needed

• Loudspeaker
• 2 Loudspeakers

• Material
• Wooden case

• from Radiomuseum.org
• Model: Speaker System D-105M - Onkyo, Osaka Denki Onkyo K.K.;

• Shape
• Tablemodel, high profile (upright - NOT Cathedral nor decorative).

• Dimensions (WHD)
• 120 x 216 x 161 mm / 4.7 x 8.5 x 6.3 inch

• Notes

• Onkyo 2-Way 2-Driver Loudspeaker System Model D-105M.
  Frequency Response: 80Hz to 35kHz
  Power Handling: 50 Watts
  Crossover Frequency: 3000Hz
  Impedance: 6Ω
  Sensitivity: 85dB/W/m
  Drivers:
  Bass: 1x 90mm Cone Type
  Tweeter: 1x 25mm Soft Dome Type
  Enclosure: 2.1 litre, Bass Reflex System


• Net weight (2.2 lb = 1 kg)
• 1.9 kg / 4 lb 3 oz (4.185 lb)

• Mentioned in
• - - Manufacturers Literature (Service Manual)

• Author
• Model page created by Franz Scharner. See "Data change" for further contributors.
