• Country
• Japan

• Manufacturer / Brand
• Onkyo, Osaka Denki Onkyo K.K.; Osaka

• Year
• 2000 ??

• Category
• Loudspeaker, headphone or earphone

• Radiomuseum.org ID
• 281632

Click on the schematic thumbnail to request the schematic as a free document.

• Wave bands
• - without

• Power type and voltage
• No Power needed

• Loudspeaker
• 2 Loudspeakers

• Material
• Wooden case

• from Radiomuseum.org
• Model: Speaker System D-N3XA - Onkyo, Osaka Denki Onkyo K.K.;

• Shape
• Tablemodel, high profile (upright - NOT Cathedral nor decorative).

• Dimensions (WHD)
• 138 x 220 x 237 mm / 5.4 x 8.7 x 9.3 inch

• Notes

• Onkyo 2-way 2-driver speaker system model D-N3XA.
  Frequency Response: 60Hz to 35kHz
  Power Handling: 70 Watts
  Crossover Frequency: 10000Hz
  Impedance: 5Ω
  Sensitivity: 84dB/W/m
  Drivers:
  Bass: 1x 120mm OMF cone Type
  Tweeter: 1x 25mm dome Type
  Enclosure: 4.5 litres, bass reflex system
  Detachable Grille


• Net weight (2.2 lb = 1 kg)
• 3 kg / 6 lb 9.7 oz (6.608 lb)

• Mentioned in
• - - Manufacturers Literature (Service Manual)

• Author
• Model page created by Franz Scharner. See "Data change" for further contributors.
