IC FM ZF Verstärker mit Demodulator Bausatz B31

Oppermann Electronic, Sachsenhagen

Data
Forum
Pictures
Collections

  • Year
  • 1975 ??
  • Category
  • Kit (Parts plus instruction) or building instructions only
  • Radiomuseum.org ID
  • 297986

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • 2
  • Main principle
  • Radio Frequency Amplification only; ZF/IF 10700 kHz
  • Wave bands
  • - without
  • Power type and voltage
  • Powered by external power supply or a main unit. / 12 Volt
  • Loudspeaker
  • - For headphones or amp.
  • Material
  • Printed Circuit Board
  • from Radiomuseum.org
  • Model: IC FM ZF Verstärker mit Demodulator Bausatz B31 - Oppermann Electronic,
  • Shape
  • Chassis only or for «building in»
  • Notes

  • Oppermann FM-ZF-Baugruppe mit 2-stufigem Transistorverstärker, 2 Keramikfiltern sowie IC mit Begrenzer-Verstärker und Koinzidenzdemodulator.

  • Literature/Schematics (1)
  • -- Original-techn. papers.
  • Author
  • Model page created by Rudolf Müller. See "Data change" for further contributors.
