• Country
• Germany

• Manufacturer / Brand
• Oppermann Electronic, Sachsenhagen

• Year
• 1975 ??

• Category
• Kit (Parts plus instruction) or building instructions only

• Radiomuseum.org ID
• 298480

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors

• Semiconductors
• BC107 BC107 BC107 BC107 BC107 BC107 BC107 BC177 1N4148 1N4148 1N4148 1N4148 TIC226 TIC226 TIC226 TIC226

• Main principle
• Audio-Amplification; none

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 220VAC Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Printed Circuit Board

• from Radiomuseum.org
• Model: Vier Kanal Lichtorgel Bausatz B80 - Oppermann Electronic,

• Notes

• Bausatz für eine 4 Kanal Lichtorgel mit Glühlampen, welche von Tyristoren, auf 4 Frequenzbereiche aufgeteilt, angesteuert werden.

• Mentioned in
• -- Original-techn. papers.

• Author
• Model page created by Rudolf Müller. See "Data change" for further contributors.
