• Country
• Hungary

• Manufacturer / Brand
• Orion; Budapest

• Year
• 1932–1934

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 17926

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 4

• Valves / Tubes
• HP4100 DS4101 APP4120 PV495

• Main principle
• Superheterodyne (common); Reflex

• Tuned circuits
• 7 AM circuit(s)

• Wave bands
• Broadcast (MW) and Long Wave.

• Power type and voltage
• Alternating Current supply (AC) / 110; 125; 150; 220; 250 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil)

• Material
• Wooden case

• from Radiomuseum.org
• Model: 7133 - Orion; Budapest

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 370 x 280 x 245 mm / 14.6 x 11 x 9.6 inch

• Net weight (2.2 lb = 1 kg)
• 11 kg / 24 lb 3.7 oz (24.229 lb)

• Price in first year of sale
• 284.00 Pengő

• External source of data
• E. Erb 3-907007-36-0

• Circuit diagram reference
• Die «Thali Schemasammlung» führt das Modell.
