• Country
• Hungary

• Manufacturer / Brand
• Orion; Budapest

• Year
• 1951

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 73777

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 8

• Valves / Tubes
• EF22 ECH21 EF22 ECH21 EM4 EBL21 EBL21 AZ21

• Main principle
• Superhet with RF-stage; ZF/IF 473,6 kHz

• Tuned circuits
• 7 AM circuit(s)

• Wave bands
• Broadcast, Long Wave and more than two Short Wave bands.

• Power type and voltage
• Alternating Current supply (AC) / 110-220 Volt

• Loudspeaker
• 2 Loudspeakers

• Material
• Wooden case

• from Radiomuseum.org
• Model: 881 - Orion; Budapest

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 630 x 380 x 303 mm / 24.8 x 15 x 11.9 inch

• Notes
• 7 Skalenscheibenstreifen senkrecht angeordnet, Fahrstuhlzeiger

• Net weight (2.2 lb = 1 kg)
• 21 kg / 46 lb 4.1 oz (46.256 lb)

• Mentioned in
• Rádiókészülékek Kapcsolásai 1936-56

• Author
• Model page created by Hermann Jung. See "Data change" for further contributors.
