Television AT501

• Country
• Hungary

• Manufacturer / Brand
• Orion; Budapest

• Year
• 1958

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 83553

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 21

• Valves / Tubes
• PCF82 PCC84 PABC80 PL82 PL83 EF80 ECL80 DY80 ECC82 PL81 PY83 PY82 43SCP4 or AW43-20

• Main principle
• Superheterodyne (common)

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• 2 Loudspeakers / Ø 6.5 inch = 16.5 cm

• Power out
• 2 W (unknown quality)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Television AT501 - Orion; Budapest

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 580 x 550 x 450 mm / 22.8 x 21.7 x 17.7 inch

• Notes

• Fernsehtischempfänger nach OIR Norm.

  Screen: 43 cm.

• Net weight (2.2 lb = 1 kg)
• 35 kg / 77 lb 1.5 oz (77.093 lb)

• Price in first year of sale
• 5,500.00 HUF

• Mentioned in
• Radio es Televizio Vevö keszülekek, 1956-57

• Author
• Model page created by Folkert Rothe. See "Data change" for further contributors.
