• Country
• Belgium

• Manufacturer / Brand
• Orthodyne Radio; J. Bonhomme; Liège, Bruxelles

• Year
• 1937/1938

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 216849

• Number of Tubes
• 7

• Valves / Tubes
• 6D6 6A7 6D6 75 6G5 42 80

• Main principle
• Superhet with RF-stage

• Tuned circuits
• 9 AM circuit(s)

• Wave bands
• Broadcast, Long Wave and Short Wave.

• Power type and voltage
• Alternating Current supply (AC) / 110-240 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 26 cm = 10.2 inch

• Material
• Wooden case

• from Radiomuseum.org
• Model: 387 - Orthodyne Radio; J. Bonhomme;

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 680 x 300 x 300 mm / 26.8 x 11.8 x 11.8 inch

• Notes

• 3 wavebands from 16 to 2000 m. Tone control.

• Price in first year of sale
• 2,550.00 BFR

• Mentioned in
• -- Original prospect or advert (Série 1938)

• Author
• Model page created by David Roussel. See "Data change" for further contributors.
