24ST1-U Ch= 88S1-U
Packard Bell Co.; Los Angeles (CA)
- Country
- United States of America (USA)
- Manufacturer / Brand
- Packard Bell Co.; Los Angeles (CA)
- Year
- 1956 ?
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 277357
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 20
- Valves / Tubes
- 6BZ7 6AF4 6U8 6CB6 6CB6 6AS8 6AW8 6AU6 6T8 6AQ5 6BY6 6S4 6AL5 6CG7 6BQ6GTB 6CU6 6AX4GT 1B3GT 5U4GB 21ALP4A
- Main principle
- Superhet with RF-stage
- Wave bands
- VHF incl. FM and/or UHF (see notes for details)
- Power type and voltage
- Alternating Current supply (AC) / 60 cycles, 117V = 110 -120 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 inch = 10.2 cm
- Material
- Wooden case
- from Radiomuseum.org
- Model: 24ST1-U Ch= 88S1-U - Packard Bell Co.; Los Angeles
- Shape
- Tablemodel, with any shape - general.
- Notes
-
THE PACKARD-BELL model 24ST1-U is a 24" b/w TV with US standard VHF Tuner channels 2 thru 13, 14 thru 83 UHF.Equipped with UHF-VHF tuner 10544, chassis 88S1 and picture tube 24DP4.
- Literature/Schematics (1)
- Photofact Folder, Howard W. SAMS (Set 312 folder 9)
- Literature/Schematics (2)
- Photofact Folder, Howard W. SAMS (Set 334 Folder 1 dated 10-56)
- Author
- Model page created by Dirk Taekels. See "Data change" for further contributors.
