• Country
• Japan

• Manufacturer / Brand
• Panasonic, Matsushita, National ナショナル (also tubes); Osaka

• Year
• 1969 ??

• Category
• Citizen Band Equipment

• Radiomuseum.org ID
• 336037

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 12

• Semiconductors
• 2SC921 2SC920 2SC829 2SC829 2SB173 2SB173 2SB175 2SB324 2SB324 2SC478 2SC697 2SC828 OA90 1S1211

• Main principle
• Transceiver; ZF/IF 455 kHz

• Wave bands
• Short Wave (SW only)

• Power type and voltage
• Dry Batteries / AA: 8 x 1.5 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 6.5 cm = 2.6 inch

• Material
• Metal case

• from Radiomuseum.org
• Model: 2-Channel Citizen Band Transceiver RJ-20EB - Panasonic, Matsushita,

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 85 x 261 x 45 mm / 3.3 x 10.3 x 1.8 inch

• Notes

• National Panasonic 2-Channel CB transceiver RJ-20EB,

  • Ch A = 26.965 MHz
  • Ch B = 27.275 MHz

  See also the similar models RJ-20E and RJ-20A.

• Net weight (2.2 lb = 1 kg)
• 0.8 kg / 1 lb 12.2 oz (1.762 lb)

• Mentioned in
• - - Manufacturers Literature

• Author
• Model page created by Peter Löytynoja. See "Data change" for further contributors.
