• Country
• Japan

• Manufacturer / Brand
• Panasonic, Matsushita, National ナショナル (also tubes); Osaka

• Year
• 2016 ?

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 332175

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors
• 80R1K2P UF5404 LD1117

• Main principle
• DSP, Digital Signal Processor

• Wave bands
• Wave Bands given in the notes.

• Power type and voltage
• Alternating Current supply (AC) / 220-240 Volt

• Loudspeaker
• 2 Loudspeakers

• Power out
• 16 W (unknown quality)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: LED TV TX-39EW334 Ch= MB140 - Panasonic, Matsushita,

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 889 x 595 x 208 mm / 35 x 23.4 x 8.2 inch

• Notes

• Bildschirm: 16/9 39" = ca. 1m Diagonale

  Empfangskanäle: VHF, UHF. Hyperband

  Digitaler Empfang: DVB-T-C-S, DVB-Te DVB-S2

  eingetragene Abmesungen mit Standfuß,
  ohne Standfuß: 889 x 523 x 78/98 mm

• Net weight (2.2 lb = 1 kg)
• 8.1 kg / 17 lb 13.5 oz (17.841 lb)

• Mentioned in
• - - Manufacturers Literature

• Author
• Model page created by Heribert Jung. See "Data change" for further contributors.
