• Country
• Japan

• Manufacturer / Brand
• Panasonic, Matsushita, National ナショナル (also tubes); Osaka

• Year
• 1968 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 205489

• Number of Transistors
• 14

• Semiconductors
• 2SC920 2SC920 2SC920 2SC945 2SC945 2SC920 2SC920 2SC829 2SC828 2SC945 2SC945 2SD261 2SD261 2SC945

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast plus 2 Short Wave bands.

• Power type and voltage
• Dry Batteries / 3 x 1,5 Volt

• Loudspeaker
• 2 Loudspeakers / Ø 9 cm = 3.5 inch

• Power out
• 1 W (unknown quality)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: 3-Band 2-Speaker 14-Transistor R-358 - Panasonic, Matsushita,

• Dimensions (WHD)
• 11.25 x 5.83 x 2.5 inch / 286 x 148 x 64 mm

• Notes
• National Panasonic R-358, 3-Band 2-Speaker 14-Transistor;
  SW1: 2.3 - 7 MHz,
  SW2: 7 - 22 MHz,
  three(!) built-in meters for volume, tuning/batt. and fine tuning, tone high/low switch, ant. & earth jacks, made in Japan. Compare with similar but with mains supply equiped version R-358B.

• Author
• Model page created by a member from A. See "Data change" for further contributors.
