Cassette Radio Phono 3-in-1 SG-106
Panasonic, Matsushita, National ナショナル (also tubes); Osaka
- Country
- Japan
- Manufacturer / Brand
- Panasonic, Matsushita, National ナショナル (also tubes); Osaka
- Year
- 1973–1975
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 338630
Gumtree-au_1294751487
Gumtree-au_1294751487
Gumtree-au_1294751487
Gumtree-au_1294751487
Gumtree-au_1294751487
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast plus 2 Short Wave bands.
- Details
- Other Combination - see Notes
- Power type and voltage
- Line / Batteries (any type) / 100-115; 115-130; 200-225; 225-250 / D: 4 x 1.5 Volt
- Loudspeaker
- 2 Loudspeakers
- Power out
- 1.6 W (unknown quality)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Cassette Radio Phono 3-in-1 SG-106 - Panasonic, Matsushita,
- Shape
- Portable set > 8 inch (also usable without mains)
- Dimensions (WHD)
- 348 x 280 x 110 mm / 13.7 x 11 x 4.3 inch
- Notes
-
National Model SG106
De-luxe portable AC/DC 3-in-1 with 3-band radio, 2-speed record player and cassette recorder with auto stop. 1.6 watts of output. Operates on 4 x UM1 batteries (D cells) or house current. (FROM MINGAY'S PRICE SERVICE)
See also Model SG-106F with FM.
- Net weight (2.2 lb = 1 kg)
- 4.4 kg / 9 lb 11.1 oz (9.692 lb)
- Price in first year of sale
- 185.00 AUS $
- Mentioned in
- Mingay's Price Service (Feb 1974 to Feb 1975.)
- Author
- Model page created by Martin Kent. See "Data change" for further contributors.
