FM/AM Portable Radio RF-H830
Panasonic, Matsushita, National ナショナル (also tubes); Osaka
- Country
- Japan
- Manufacturer / Brand
- Panasonic, Matsushita, National ナショナル (also tubes); Osaka
- Year
- 1995
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 283418
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Main principle
- PLL, Phase-locked loop
- Wave bands
- Broadcast (BC) and FM or UHF.
- Details
- Radio with other functions
- Power type and voltage
- Dry Batteries / UM-4: 2 x 1.5 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 3.6 cm = 1.4 inch
- Power out
- 0.125 W (unknown quality)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: FM/AM Portable Radio RF-H830 - Panasonic, Matsushita,
- Shape
- Very small Portable or Pocket-Set (Handheld) < 8 inch.
- Dimensions (WHD)
- 55 x 99 x 17 mm / 2.2 x 3.9 x 0.7 inch
- Notes
-
Europa-Mono-Radio mit bis zu 179 vorgespeicherten Sendern aus 15 europäischen Ländern (Deuschland: Hamburg, Berlin, Frankfurt, München), automatischer Sendersuchlauf, Weckfunktion über Lautsprecher oder Ohrhörer.
- Net weight (2.2 lb = 1 kg)
- 0.067 kg / 0 lb 2.4 oz (0.148 lb)
- Mentioned in
- -- Original prospect or advert (Herstellerprospekt: Panasonic Audio 1995, Seite 20)
- Author
- Model page created by Roland Müller. See "Data change" for further contributors.
