• Country
• Japan

• Manufacturer / Brand
• Panasonic, Matsushita, National ナショナル (also tubes); Osaka

• Year
• 1960 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 258285

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 9

• Semiconductors
• 2SA71 or. OC171 2SA71 or. OC171 2SA70 or. OC170 2SA70 or. OC170 2SA70 or. OC170 2SB171 or. OC71 2SB171 or. OC71 2SB176 or. OC76 2SB176 or. OC76 OA70 OA79 MA23

• Main principle
• Superheterodyne (common); ZF/IF 455/10700 kHz

• Wave bands
• Broadcast (BC) and FM or UHF.

• Power type and voltage
• Dry Batteries / AA: 4 x 1,5 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Power out
• 0.2 W (0.35 W max.)

• from Radiomuseum.org
• Model: National AM-FM T-30 - Panasonic, Matsushita,

• Shape
• Portable set > 8 inch (also usable without mains)

• Notes

• Frequency Range

  AM: 535 - 1605 kHz

  FM: 88 - 108 MHz

  External FM/AM/Earth jacks, Two earphone and external jacks.



• Mentioned in
• -- Schematic

• Author
• Model page created by Daniel Rosha. See "Data change" for further contributors.
