Panasonic Video Cassette Recorder NV-HS800EG

Panasonic, Matsushita, National ナショナル (also tubes); Osaka

Data
Forum
Pictures
Collections

  • Year
  • 1994
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 281384

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • VHF incl. FM and/or UHF (see notes for details)
  • Details
  • Video-Taperecorder/-Player; Hi-Fi equipment
  • Power type and voltage
  • Alternating Current supply (AC) / 220-240 Volt
  • Loudspeaker
  • - For headphones or amp.
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Panasonic Video Cassette Recorder NV-HS800EG - Panasonic, Matsushita,
  • Shape
  • Book-shelf unit.
  • Dimensions (WHD)
  • 430 x 118 x 395 mm / 16.9 x 4.6 x 15.6 inch
  • Notes
  • Video Signal System CCIR:R/P|PAL: R/P|SECAM: R/P|NTSC(b/w): R/P|NTSC (color): R/P|other: R/P
    Videostandard: VHS|S-VHS
    Tuner equipped: Yes HF Output: Yes|No
    Timer: Yes|No Color: Yes
    Insert-Cut: Yes|No Controllable by Editing-System: Yes|No
    Timebas Corrector: Yes|No|Optinal RGB Video In/Out: Yes|No
    Composite (FBAS) Video In/Out: Yes|No Component Video In/Out: Yes|No|Optional
    S-Video In/Out: Yes|No Signal to Noise Video: __dB
    Horizontal Resol. black/white: ___l. Horizontal Resolution Color: ___l.
    Dropout compensator: Yes|No Wow and Flutter lin. audiotrack: __%
    No. of Audiochannels linear track: _ No. of Audiochannels helical track:

    _
    Signal to Noise linear Audio track: __dB Signal to Noise helical Audio track: __ dB
    Audio Out Sym|Asym|No Audio In Sym|Asym|No
    crosstalk lin. Audio track __dB crosstalk heli. Audio track __dB

    Audio Frequency Response : 20 Hz to 20 kHz
    Remote Control: IR|Cable|by Edit Control System|No

    HiFi-Stereo, Jog-Shuttle,
    Tuner: UHF/VHF, SP/LP Betrieb, VPS, ShowView, horizontale Videoauflösung besser als 240 Zeilen (VHS/SP), besser als 400 Zeilen (S-VHS), Dynamikbereich Audio besser als 90 dB.  Gleichlaufschwankungen 0,005% (HiFi-Tonspur)

  • Net weight (2.2 lb = 1 kg)
  • 6.8 kg / 14 lb 15.6 oz (14.978 lb)
  • Mentioned in
  • -- Original-techn. papers.
  • Author
  • Model page created by Roland Müller. See "Data change" for further contributors.
