• Country
• Japan

• Manufacturer / Brand
• Panasonic, Matsushita, National ナショナル (also tubes); Osaka

• Year
• 1998

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 296707

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Wave bands
• - without

• Details
• CD-Player, -Writer, MD, MOD (audio); Remote Control (with wire or wireless)

• Power type and voltage
• Storage and/or dry batteries / 4x1,5 Volt

• Loudspeaker
• - only for Earphone!

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: SL-SX 500 - Panasonic, Matsushita,

• Shape
• Very small Portable or Pocket-Set (Handheld) < 8 inch.

• Dimensions (WHD)
• 128 x 25.7 x 135 mm / 5 x 1 x 5.3 inch

• Notes

• Discman,( CD Player ) active memory anti shock ll up to 40 sec, 52 houres reproduction with 4 battery ( UM3 ), indicator of battery power on the LCD, remote control 3 touches, pop up system, converter D/A  MASH 1 bit, 24 tracks for random acess programming, repetition touches 1/jump, search memory, recall, real resume and random read, aut/stop, pause switch, 3 preset equalizer  normal, XBS  for more powerful bass and live, struture in heat-      resistant policarbonate.

• Net weight (2.2 lb = 1 kg)
• 0.255 kg / 0 lb 9 oz (0.562 lb)

• Mentioned in
• Panasonic Matsushita National Catalogs (Model Page 44)

• Author
• Model page created by Manuel Albano Neves. See "Data change" for further contributors.
