Panasonic FM-AM All Transistor T-81

Panasonic, Matsushita, National ナショナル (also tubes); Osaka

Data
Forum
Pictures
Collections

  • Year
  • 1962 ?
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 79868

 Technical Specifications

  • Number of Transistors
  • 8
  • Semiconductors
  • Main principle
  • Superheterodyne (common); 3 AF stage(s)
  • Wave bands
  • Broadcast (BC) and FM or UHF.
  • Power type and voltage
  • Dry Batteries / AA: 4 x 1,5 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical / Ø 10 cm = 3.9 inch
  • Power out
  • 0.3 W (unknown quality)
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Panasonic FM-AM All Transistor T-81 - Panasonic, Matsushita,
  • Shape
  • Very small Portable or Pocket-Set (Handheld) < 8 inch.
  • Dimensions (WHD)
  • 200 x 110 x 43 mm / 7.9 x 4.3 x 1.7 inch
  • Notes
  • 2 x 2SA71, 2 x 2SA70, 2SB173, 2SB175, 2 x 2SB176. Ausführung T-81L Bereiche U-M-L.
  • Net weight (2.2 lb = 1 kg)
  • 0.7 kg / 1 lb 8.7 oz (1.542 lb)
  • Price in first year of sale
  • 59.95 US$
  • Source of data
  • -- Collector info (Sammler)
  • Mentioned in
  • -- Original prospect or advert
  • Author
  • Model page created by Marc Gianella. See "Data change" for further contributors.
