Paramount 5V
Paramount Radio Ltd.; Christchurch
- Country
- New Zealand-Aotearoa
- Manufacturer / Brand
- Paramount Radio Ltd.; Christchurch
- Year
- 1941
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 332662
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common); 2 AF stage(s)
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Alternating Current supply (AC) / 230 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 6 inch = 15.2 cm
- Material
- Wooden case
- from Radiomuseum.org
- Model: Paramount 5V - Paramount Radio Ltd.;
- Shape
- Tablemodel, Tombstone = decorative upright, not cathedral but can have rounded edges.
- Dimensions (WHD)
- 240 x 315 x 205 mm / 9.4 x 12.4 x 8.1 inch
- Notes
-
5 valve superhet broadcast (MW) compact model receiver available in de luxe polished cabinets or Dulux finish to match any room.
- Price in first year of sale
- 10.50 NZ £
- Mentioned in
- More Golden Age of Radio (Page 146)
- Author
- Model page created by Brian Stevens. See "Data change" for further contributors.
