- Country
- United States of America (USA)
- Manufacturer / Brand
- Pathe Phono & Radio Co.; Brooklyn
- Year
- 1935 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 216219
-
- Brand: Minute Man
- Number of Tubes
- 4
- Main principle
- TRF (Tuned-Radio-Frequency but use of regeneration unknown); ZF/IF none kHz; 1 AF stage(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- AC/DC-set / 110 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 4 inch = 10.2 cm
- Material
- Leather / canvas / plastic - over other material
- from Radiomuseum.org
- Model: unknown - Pathe Phono & Radio Co.;
- Shape
- Tablemodel without push buttons, Mantel/Midget/Compact up to 14
- Dimensions (WHD)
- 9 x 7 x 5 inch / 229 x 178 x 127 mm
- Notes
- Repair hint: The circuitry (only) appears to be identical to the Zephyr Radio Company model RKD. See Riders, Zephyr 10-1.
- Net weight (2.2 lb = 1 kg)
- 2 lb (2 lb 0 oz) / 0.908 kg
- Circuit diagram reference
- Rider's Perpetual, Volume 10 = 1939 and before
- Author
- Model page created by David Leishman. See "Data change" for further contributors.
