Current Clamp Adapter - Zangenadapter - Stromzange P 4250

PeakTech GmbH, Heinz-Günther Lau (HGL, H.G.L., Exacta); Ahrensburg

Data
Forum
Pictures
Collections

  • Year
  • 2010 ??
  • Category
  • Service- or Lab Equipment
  • Radiomuseum.org ID
  • 357068

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Wave bands
  • - without
  • Power type and voltage
  • Dry Batteries / PP3: 1 x 9 Volt
  • Loudspeaker
  • - - No sound reproduction output.
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Current Clamp Adapter - Zangenadapter - Stromzange P 4250 - PeakTech GmbH, Heinz-Günther
  • Shape
  • Very small Portable or Pocket-Set (Handheld) < 8 inch.
  • Dimensions (WHD)
  • 195 x 70 x 33 mm / 7.7 x 2.8 x 1.3 inch
  • Notes

  • In combination with a multimeter, the PeakTech P 4250 Current Clamp Adapter enables in-circuit non-contact measurements of currents up to 60 A. The instrument has two ranges and is powered by a 9 V PP3 battery, which has a life of about 100 hours.

    Output 1 mV/10 mA; 1 mV/100 mA
    Maximum current DC or AC 60 A
    Frequency range 0 - 20 kHz
    Zero set switch for DC current measurement
    Load resistance 10 kΩ typical
    Max conductor diameter 9 mm
    4 mm safety plug connectors
    Power on (green) and low battery (red) LEDs
    Overvoltage category II (Max 300 V DC or 240 V AC)
    Operating environment 0 to 50 ˚C at < 70% RH
    Storage environment -20 to 60 ˚C at < 80% RH

  • Net weight (2.2 lb = 1 kg)
  • 0.244 kg / 0 lb 8.6 oz (0.537 lb)
  • Mentioned in
  • - - Manufacturers Literature (Operation manual)
  • Author
  • Model page created by Bruce Taylor. See "Data change" for further contributors.
