Professional Stereo Power Amplifier PV-1.3K
Peavey Electronics, Meridian - Mississippi
- Country
- United States of America (USA)
- Manufacturer / Brand
- Peavey Electronics, Meridian - Mississippi
- Year
- 1994
- Category
- Audio Amplifier or -mixer
- Radiomuseum.org ID
- 250448
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Power type and voltage
- Alternating Current supply (AC) / 50 to 60 cycles, 220 to 240 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Power out
- 2000 W (undistorted)
- Material
- Metal case
- from Radiomuseum.org
- Model: Professional Stereo Power Amplifier PV-1.3K - Peavey Electronics, Meridian
- Shape
- Rack
- Dimensions (WHD)
- 483 x 178 x 356 mm / 19 x 7 x 14 inch
- Notes
-
Power out:
8 Ohm Bridged 1300W RMS mono
4 Ohm Bridged 2000W RMS mono
8 Ohm Stereo 400W RMS per channel
4 Ohm Stereo 650W RMS per channel
2 Ohm Stereo 1000W RMS per channel
Frequency Response: 20Hz-20kHz
Total Harmonic Distortion: les than 0,1% rated power
- Net weight (2.2 lb = 1 kg)
- 25 kg / 55 lb 1.1 oz (55.066 lb)
- Author
- Model page created by Bartosz Szwed. See "Data change" for further contributors.
