- Country
- Worldwide
- Manufacturer / Brand
- Peerless (brand - far east tube and transistor products)
- Year
- 1964
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 141245
Sams Photofact Folders
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)
- Tuned circuits
- 5 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Alternating Current supply (AC) / 110 - 120 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 3 inch = 7.6 cm
- from Radiomuseum.org
- Model: 505 - Peerless brand - far east tube
- Shape
- Tablemodel without push buttons, Mantel/Midget/Compact up to 14
- Notes
- The Peerless Model 505 is an AC Operated 5 Tube AM Receiver.
- Literature/Schematics (1)
- Photofact Folder, Howard W. SAMS (Date 3-65, Set 746, Folder 6)
- Author
- Model page created by Egon Penker. See "Data change" for further contributors.
