6 Transistor 630
Peerless (brand - far east tube and transistor products)
- Country
- Worldwide
- Manufacturer / Brand
- Peerless (brand - far east tube and transistor products)
- Year
- 1963 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 332222
- Number of Transistors
- 6
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Dry Batteries / 1 x 9 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 2.25 inch = 5.7 cm
- Material
- Various materials
- from Radiomuseum.org
- Model: 6 Transistor 630 - Peerless brand - far east tube
- Shape
- Very small Portable or Pocket-Set (Handheld) < 8 inch.
- Dimensions (WHD)
- 67 x 109 x 32 mm / 2.6 x 4.3 x 1.3 inch
- Notes
-
Brush bronze metal front on smooth black plastic cabinet. Glittery green speckles on grille cloth. US civil defense marks on station dial. Thick leather carrying case.
Made in Japan
- Mentioned in
- Transistor Radios (Page 196)
- Literature/Schematics (1)
- Photofact TSM Transistor Radio Series SAMS (TSM-52, April 1965)
- Author
- Model page created by Ray Albright. See "Data change" for further contributors.
- Other Models
-
Here you find 45 models, 41 with images and 2 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
All listed radios etc. from Peerless (brand - far east tube and transistor products)
Collections
The model 6 Transistor is part of the collections of the following members.
