Flugfunk-Empfänger H208
Peravia; Schweiz
- Country
- Switzerland
- Manufacturer / Brand
- Peravia; Schweiz
- Year
- 1940 ??
- Category
- Commercial Receiver (may include amateur bands)
- Radiomuseum.org ID
- 359835
- Number of Tubes
- 4
- Main principle
- Superhet with RF-stage; ZF/IF 460 kHz; 1 AF stage(s)
- Tuned circuits
- 7 AM circuit(s)
- Wave bands
- Short Wave (SW only)
- Power type and voltage
- Powered by external power supply or a main unit. / 6,3 & 250 Volt
- Loudspeaker
- - For headphones or amp.
- Material
- Metal case
- from Radiomuseum.org
- Model: Flugfunk-Empfänger H208 - Peravia; Schweiz
- Shape
- Rack
- Dimensions (WHD)
- 270 x 190 x 180 mm / 10.6 x 7.5 x 7.1 inch
- Notes
-
Flugfunkempfänger. Umschalter Telefonie - Telegraphie.
3 Bereiche:
- 14.0 - 7.9 MHz
- 8.2 - 4.5 MHz
- 4.8 - 2.6 MHz
- Net weight (2.2 lb = 1 kg)
- 3.6 kg / 7 lb 14.9 oz (7.93 lb)
- Author
- Model page created by August Weidenholzer. See "Data change" for further contributors.
