hifi studio 20 Schleiflack
Perpetuum-Ebner (PE); St.Georgen
- Country
- Germany
- Manufacturer / Brand
- Perpetuum-Ebner (PE); St.Georgen
- Year
- 1972/1973
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 28769
Q: Perpetuum-Ebner, Produkt-Katalog 1972/73
PE-Prospekt Die Perfektion von 1972-73
Gerät steht im Phonomuseum St. Georgen
Gerät steht im Phonomuseum St. Georgen
Gerät steht im Phonomuseum St. Georgen
- Number of Transistors
- 45
- Semiconductors
- Main principle
- Superheterodyne (common); ZF/IF 460/10700 kHz
- Tuned circuits
- 7 AM circuit(s) 20 FM circuit(s)
- Wave bands
- Broadcast, (BC) Long Wave (LW), 2 x SW and FM or UHF.
- Details
- Changer (Record changer)
- Power type and voltage
- Alternating Current supply (AC) / 110; 220 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Material
- Wooden case
- from Radiomuseum.org
- Model: hifi studio 20 [Schleiflack] - Perpetuum-Ebner PE; St.Georgen
- Shape
- Tablemodel with Push Buttons.
- Dimensions (WHD)
- 690 x 200 x 340 mm / 27.2 x 7.9 x 13.4 inch
- Notes
-
Vollstereo, NF-Verstärker mit zwei Endstufen je 20 W (Sinus);
Phono-Chassis = PE3060 mit Stereo-Magnetsystem Shure DM101M-G.
- Net weight (2.2 lb = 1 kg)
- 14.6 kg / 32 lb 2.5 oz (32.159 lb)
- Price in first year of sale
- 1,515.00 DM
- External source of data
- Erb
- Source of data
- Handbuch VDRG 1972/1973 / Radiokatalog Band 2, Ernst Erb
