• Country
• Germany

• Manufacturer / Brand
• Perpetuum-Ebner (PE); St.Georgen

• Year
• 1969/1970

• Category
• Audio Amplifier or -mixer

• Radiomuseum.org ID
• 27738

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 22

• Semiconductors
• BC109 BC107 2N2218 2N2904 2N3055

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 110; 220 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Material
• Wooden case

• from Radiomuseum.org
• Model: HSV80 - Perpetuum-Ebner PE; St.Georgen

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 450 x 105 x 260 mm / 17.7 x 4.1 x 10.2 inch

• Notes
• Tranistoren: 12× BC109, 2×BC107, 2×2N2218, 2×2N2904, 4× 2N3055

  Stereo-NF-Verstärker mit 2 Endstufen je 20 W (Sinus).

• Net weight (2.2 lb = 1 kg)
• 6.5 kg / 14 lb 5.1 oz (14.317 lb)

• Price in first year of sale
• 648.00 DM

• External source of data
• erb

• Source of data
• Handbuch VDRG 1969/1970 / Radiokatalog Band 2, Ernst Erb

• Mentioned in
• Funk-Technik (FT) (9/1969, S. 336, 337 / Beschreibung, Daten, Schema)
