Direct Coupled Solid State Amplifier 400
Phase Linear; Edmonds (WA)
- Country
- United States of America (USA)
- Manufacturer / Brand
- Phase Linear; Edmonds (WA)
- Year
- 1972
- Category
- Audio Amplifier or -mixer
- Radiomuseum.org ID
- 151175
Prospekt
Hi-Fi Arbogen 1973 page 81 (Danmark)
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Details
- Hi-Fi equipment
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Power out
- 400 W (800 W max.)
- Material
- Metal case
- from Radiomuseum.org
- Model: Direct Coupled Solid State Amplifier 400 - Phase Linear; Edmonds WA
- Shape
- Rack
- Dimensions (WHD)
- 19 x 7 x 10 inch / 483 x 178 x 254 mm
- Notes
-
Stereo power amplifier with 200 WRMS per channel into 8 Ω, 400 WRMS per channel into 4 Ω.
Twin output meters, six output transistors per channel, plus two drivers per channel.
Frequency response of 0-250 kHz.
- Price in first year of sale
- 499.00 $
- Author
- Model page created by Franz Scharner. See "Data change" for further contributors.
