10H25R

Philco, Philadelphia Stg. Batt. Co.; USA

Data
Forum
Pictures
Collections

  • Year
  • 1959
  • Category
  • Television Receiver (TV) or Monitor
  • Radiomuseum.org ID
  • 213038

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 15
  • Main principle
  • Superhet with RF-stage
  • Wave bands
  • VHF incl. FM and/or UHF (see notes for details)
  • Power type and voltage
  • Alternating Current supply (AC) / 105-120 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: 10H25R - Philco, Philadelphia Stg. Batt
  • Shape
  • Chassis only or for «building in»
  • Notes
  • The Philco 10H25R is a chassis for 17" b/w TV's with US standard VHF Tuner channels 2 thru 13. Used in various "H" line Philco TV's. Uses VHF tuner T-72A and picture tube 17DRP4. This chassis is similar to chassis 10H25 with the addition of the "New-Matic" remote tuning feature.
  • Source of data
  • - - Manufacturers Literature
  • Literature/Schematics (1)
  • - - Manufacturers Literature
  • Author
  • Model page created by John Kusching. See "Data change" for further contributors.
