49-1150 Code 124

• Country
• United States of America (USA)

• Manufacturer / Brand
• Philco, Philadelphia Stg. Batt. Co.; USA

• Year
• 1949 ?

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 264958

• Picture
• Schematics

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 26

• Valves / Tubes
• 6AG5 6AG5 6J6 6AG5 6AG5 6AG5 6AG5 6AL5 12AU7 7F7 6BA6 6AU6 6AL5 6AU6 6K6GT 7N7 7N7 6K6GT 7N7 6BG6 5V4G 1B3GT 1B3GT 5U4G 7Z4 10BP4

• Main principle
• Superhet with RF-stage; ZF/IF 22100/26600 kHz; 2 AF stage(s)

• Wave bands
• VHF incl. FM and/or UHF (see notes for details)

• Power type and voltage
• Alternating Current supply (AC) / 60 cycle, 110-120 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Wooden case

• from Radiomuseum.org
• Model: 49-1150 Code 124 - Philco, Philadelphia Stg. Batt

• Shape
• Console, Highboy (legs > 50 %).

• Notes

• The Philco 49-1150 Code 124 is a 10" b/w TV with US standard VHF Tuner channels 2 thru 13. Equipped with picture tube 10BP4.

  See also Philco 49-1150 Code 121
