• Country
• New Zealand-Aotearoa

• Manufacturer / Brand
• Dominion Radio & Electrical Corp. Ltd (Dreco), Philco; Auckland

• Year
• 1950

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 167313

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 6

• Valves / Tubes
• 7B7 7S7 7B7 7C6 7C5 5Y3GT

• Main principle
• Superhet with RF-stage; ZF/IF 455 kHz; 2 AF stage(s)

• Tuned circuits
• 7 AM circuit(s)

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• Alternating Current supply (AC) / 230 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 8 inch = 20.3 cm

• Material
• Wooden case

• from Radiomuseum.org
• Model: Philco 611 - Dominion Radio & Electrical

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 560 x 300 x 330 mm / 22 x 11.8 x 13 inch

• Notes

• This model appears in a list compiled by John Stokes during his research into the history of New Zealand radio.

  6-valve superhet with RF stage

• Mentioned in
• -- Original prospect or advert (Otago Daily Times 23 November 1950 Page 5)

• Author
• Model page created by Keith Staines. See "Data change" for further contributors.
