• Country
• Canada

• Manufacturer / Brand
• Philco Products Ltd.; Toronto

• Year
• 1940/1941

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 206125

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• 6A8EG 6K7EG 6Q7G 6K6EG 80

• Main principle
• Superheterodyne (common); ZF/IF 460 kHz; 2 AF stage(s)

• Tuned circuits
• 5 AM circuit(s)

• Wave bands
• Broadcast and Short Wave (SW).

• Power type and voltage
• Alternating Current supply (AC) / 115 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil)

• Material
• Wooden case

• from Radiomuseum.org
• Model: 48T Code 121 - Philco Products Ltd.; Toronto

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 320 x 210 x 170 mm / 12.6 x 8.3 x 6.7 inch

• Notes

• Matched walnut cabinet.

• Price in first year of sale
• 46.95 CAD

• Literature/Schematics (1)
• Radio College of Canada (RCC) (Philco p.102)

• Literature/Schematics (2)
• The Winnipeg Tribune; 1941-11-21

• Author
• Model page created by Frank Van de Ven. See "Data change" for further contributors.
