- Country
- Canada
- Manufacturer / Brand
- Philco Products Ltd.; Toronto
- Year
- 1952 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 293856
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 8
- Main principle
- Superhet with RF-stage; ZF/IF 460 kHz
- Tuned circuits
- 7 AM circuit(s)
- Wave bands
- Broadcast and Short Wave (SW).
- Details
- Record Player (perh.Changer)
- Power type and voltage
- Alternating Current supply (AC) / 117 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Power out
- 10 W (unknown quality)
- Material
- Wooden case
- from Radiomuseum.org
- Model: 742 - Philco Products Ltd.; Toronto
- Shape
- Console with any shape - in general
- Notes
-
The Canadian Philco model 742 is a combination radio / 4-speed record changer console. Covers standard broadcast and 5.5-15 MHz shortwave. Has intenal loop for BC reception.
Model 742 for 60 Hz. Model 742-2 for 25 Hz.
- Literature/Schematics (1)
- Radio College of Canada (RCC) (Supplement 26 pages 43 and 44.)
- Author
- Model page created by Tom Seeger. See "Data change" for further contributors.
