- Country
- Canada
- Manufacturer / Brand
- Philco Products Ltd.; Toronto
- Year
- 1954 ?
- Category
- Sound/Video Recorder and/or Player
- Radiomuseum.org ID
- 301539
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 1
- Valves / Tubes
- 25L6
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Details
- Record Player (not changer)
- Power type and voltage
- Alternating Current supply (AC) / 60 Hz, 105-125 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Power out
- 1 W (unknown quality)
- Material
- Leather / canvas / plastic - over other material
- from Radiomuseum.org
- Model: 832 - Philco Products Ltd.; Toronto
- Shape
- Tablemodel, with any shape - general.
- Notes
-
The Philco model 832 is a single tube record player with selenium rectifier. Player operates at 33-1/3, 45 and 78 RPM. This model is for 60 Hz only. For 25 Hz model see Philco model 832A.
- Literature/Schematics (1)
- Radio College of Canada (RCC) (1955/1956 Supplement 36)
- Author
- Model page created by Tom Seeger. See "Data change" for further contributors.
