- Country
- Canada
- Manufacturer / Brand
- Philco Products Ltd.; Toronto
- Year
- 1965 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 324359
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 10
- Main principle
- Superheterodyne (common); ZF/IF 455/10700 kHz; 3 AF stage(s)
- Tuned circuits
- 5 AM circuit(s) 6 FM circuit(s)
- Wave bands
- Broadcast (BC) and FM or UHF.
- Power type and voltage
- Line / Batteries (any type) / Either 4 x D 1.5 or AC 117 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: NT912 - Philco Products Ltd.; Toronto
- Shape
- Portable set > 8 inch (also usable without mains)
- Notes
-
The Philco model NT912 is a 10-transistor portable AM/FM radio. Similar to USA model NT912BK.
- Literature/Schematics (1)
- Radio College of Canada (RCC) (1966 Supplement 77)
- Author
- Model page created by Tom Seeger. See "Data change" for further contributors.
