• Country
• New Zealand-Aotearoa

• Manufacturer / Brand
• Dominion Radio & Electrical Corp. Ltd (Dreco), Philco; Auckland

• Year
• 1965 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 350988

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 3

• Valves / Tubes
• ECH81 EBF80 ECL82

• Main principle
• Superheterodyne (common); 2 AF stage(s)

• Tuned circuits
• 6 AM circuit(s)

• Wave bands
• Broadcast only (MW).

• Details
• Record Player (not changer)

• Power type and voltage
• Alternating Current supply (AC) / 50Hz, 230 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

• Material
• Leather / canvas / plastic - over other material

• from Radiomuseum.org
• Model: Dreco Musicmaker Campus - Dominion Radio & Electrical

• Shape
• Tablemodel, Box - most often with Lid (NOT slant panel).

• Notes

• CAMPUS

  The "CAMPUS" is a very popular DRECO model and brings you A.C. Radio and 4-speed record player. See it now only £29/17/6.

  One of two known models.

• Price in first year of sale
• 29.88 NZ £

• Mentioned in
• -- Original prospect or advert (Press 13 December 1966 Page 8)

• Author
• Model page created by Brian Stevens. See "Data change" for further contributors.
